Stainless Steel Adapter Fitting Oil Vapor Recovery Connector Reducer Union Welding Insert Nozzle 3kg

Place of Origin : Hubei, China

Brand Name : HUATE

Model Number : HT.TQJTSS-100, HT.TQJTSS-100

Price : $42.99/pieces 1-9 pieces

Material : Stainless Steel

Nozzle : /

ambient temperature : /

Flow Rate : /

Warranty : 1YEAR

Type : European standard accessories

Product name : Stainless Steel Oil and Gas Recovery Valve

norminal diameter : DN100

norminal pressure : 0.4Mpa

Body material : stainless steel

weight : 3kg

opening method : pneumatic

sealing material : Nitrile, fluororubber, silicone

Use : oil and gas recovery

Packaging Details : Wooden box

Delivery Time : 30

Payment Terms : T/T

MOQ : 1

Supply Ability : Meet large-scale orders

Certification : CCC

Contact Now

Stainless Steel Adapter Fitting Oil Vapor Recovery Connector Reducer Union Welding Insert Nozzle 3kg
High Quality Stainless Steel Oil and Gas Recovery Joint
The oil and gas recovery joint is installed on the lower side of the tank truck near the oil discharge port, using a quick connection structure. It is an important component for controlling the input and output of oil and gas on the tank truck and achieving oil and gas recovery. The valve body is equipped with a pneumatic interlock valve, which can be triggered by valve docking to control the side plate vent valve.
Key Features
  • Constructed from durable stainless steel for corrosion resistance
  • Quick connection structure for efficient installation
  • Pneumatic interlock valve for precise control
  • Designed for oil and gas recovery applications
  • Robust construction with 3kg weight
Technical Specifications
Product Name Stainless steel oil and gas recovery joint
Raw Material Stainless steel
Nominal Diameter DN 100mm
Nominal Pressure 0.4 MPa
Working Temperature -20°C to +70°C
Weight 3KG
Seal Material Nitrile/Fluorine Rubber
